0417 032 085
Features such as HDG-II (high density oversized gearing), aluminium screw-in handle and a gear stabilization system providing the ultimate in strength and cranking power. In addition, the frictionless main shaft design effectively reduces rotational resistance, delivering an unrivalled lightweight and smooth feel.
HDG-II: Oversized High-Density Gearing
7HPB + 1RB corrosion resistant stainless-steel bearings
Multi-disc, oiled felt drag system
Quick-Set anti-reverse roller bearing
Precision machine cut brass pinion gear
Even Flow Line Roller system with DLC coating
Corrosion resistant frame, side plate and rotor
Rigid machined aluminium screw in handle design
Pinion gear: double supported with ball bearings
Frictionless main shaft design provides smooth operation
Machined aluminium, 2-tone anodized spool
Heavy duty, solid aluminium bail wire
Rotor brake system prevents rotation while casting
Model |
Gear Ratio |
Weight |
Max Drag |
Capacity: dia. mm›metres |
CHD-1000HA |
6.0:1 |
196g |
5kg |
0.15›255m 0.20›140m 0.25›90m |
CHD-2500HA |
6.0:1 |
235g |
6kg |
0.20›250m 0.25›165m 0.30›110m |
CHD-3000HA |
6.0:1 |
235g |
6kg |
0.20›310m 0.25›200m 0.30›130m |
CHD-4000XA |
6.2:1 |
273g |
9kg |
0.25›280m 0.30›180m 0.35›130m |
CHD-C5000XA |
6.2:1 |
276g |
9kg |
0.30›240m 0.35›180m 0.40›125m |
